Worklog PPR

[ShockSlayer]

I can't even hide my erection.



[Diminuendo]

But will it fit in a tic-tac case?



[Ikeprodigy]

But will it fit in a tic-tac case?

Give it about a year. We got some wizards in these forums.



[ShockSlayer]

I have a picture somewhere of the omega in an altoids tin. $5 says Gman gets a PS2 in a gameboy micro by 2018



[Ikeprodigy]

I have a picture somewhere of the omega in an altoids tin. $5 says Gman gets a PS2 in a gameboy micro by 2018

Oh that's definitely happening. I'd put $50 down.



[Noah]

Oh that's definitely happening. I'd put $50 down.

Send all payments to [email protected]



[Diminuendo]

For anyone who didn't get the reference;
http://modretro.com/xen/index.php?threads/n64-question.8610/#post-113732



[ShockSlayer]



[Shank]



[Doom]

Is Mike Ryan bringing this to display as well for mgc?



[marshallh]



[marshallh]

Boots on the 3x3 just fine. Due to how it's wired, the flex cable connects on the top rather the bottom of the 64drive. A longer cable could probalby be used for moving it around.

And with vga plus cart for scale:



[ShockSlayer]

Amazing.



[Noah]

Damn, that's really nice.

Is the battery for RTC? Noticed no other 64Drive has it.



[marshallh]

Yeah, all 64drive HW2 have the RTC along with other things. This version is just a more compact HW2.



[marshallh]

5.26 x 3.16 inches



[Noah]

brb changing my pants



[Shank]

Goddamn. So this is an n64, a 64drive, and an UltraVGA, with a connector at the top right for real cartridges?
Are all the components on one side of the board? Could it be even smaller if they were on both sides?



[Aurelio]

No LCD driver?



[Noah]

Goddamn. So this is an n64, a 64drive, and an UltraVGA, with a connector at the top right for real cartridges?
Are all the components on one side of the board? Could it be even smaller if they were on both sides?

I mean maybe but as you place more components on the back it becomes increasingly difficult to run power and ground with 4 layers because many fabs don't support buried vias. Most likely not worth the cost that you'd have to pay.

Also the N64 gets pretty warm so it might not be the best idea to have a bunch of components mounted on the back.
